Windform RS
Class of Material
Carbon fiber filled composite material polyamide based
Technology
Selective Laser Sintering
FEATURES
High stiffness/strength and high flexibilityLightweightResistant to impact even at low temperaturesResistant to shock and vibrationResistant to water and liquids from 1 mm part thicknessTop mechanical properties
KEY VALUES
Density (20° C) 1,10 g/ccHDT (1.82 Mpa) 191,9° CMelting point 197° CTensile strength - XY axis 85,25 MpaElongation @ break - XY axis 9,46%Tensile modulus - XY axis 6638,80 Mpa
APPLICATIONS
Custom production and pre-series partsHeavy-duty componentsMission-critical unitsReliable, durable functional parts
Technical Properties
Density: 1,10 g/cc
Colour:
BLACK
| Thermal Properties | Test Method | SI Unit | US Unit |
|---|---|---|---|
| Melting point | ISO 11357 | 197,00° C | 386.60° F |
| HDT, 1.82 Mpa | ISO 75 Method A | 191,90° C | 377.42° F |
| Vicat 10N | ISO 306 Method A50 | 191,90° C | 377.42° F |
Note: The material properties provided herein are for reference purposes only. Data was generated from the testing of parts produced with Windform RS material under optimal processing conditions. Actual values may vary significantly as they are affected by part geometry and process parameters. Material specifications are subject to change without notice.
Standard Technical Details for Accuracy versus Tolerance:
For parts up to 1 mm (0.039″), the standard tolerance is ± 0,070 mm (0.003″)
For parts up to 3 mm (0.118″), the standard tolerance is ± 0,125 mm (0.005″)
For parts up to 6 mm (0.236″), the standard tolerance is ± 0,150 mm (0.006″)
For parts over 6 mm (0.236″), refer to UNI EN ISO 286-2 JS14 class (linear tolerances).
Technical specifications
Windform® RS is the tenth material of the Windform® TOP-LINE range, created and developed by CRP Technology.
Windform® RS is a Black, polyamide-based SLS composite material that is Carbon fiber reinforced.
Windform® RS has excellent mechanical characteristics: it has a very high tensile strength (85,25 Mpa) and at the same time has excellent ductility (Elongation @ break 9.46%) and low density (1,10 g/cc).
It is resistant to damage, shock, vibrations, deformations and high temperatures. The combination of high resistance and high resilience makes Windform® RS unique in the AM world.
The high resilience/strength properties allow it to withstand shocks at various ranges of temperature, even sub-zero (it has been successfully tested to -40 °C, -40 °F). In addition, it is resistant to water and liquid absorption down to just 1 millimeter part thickness.
Windform® RS has been rated HB according to the flammability UL 94 test.
Windform RS has passed ESA standard screening outgassing tests for space-flight applications and it is skin contact approved.
Applications
Delivering the strongest but ductile Carbon filled composite, Windform® RS let manufacturers realize ruggedized Powder Bed Fusion parts for the most challenging applications.
Windform® RS promises maximum tensile strength, higher elongation at break and water resistance from 1 mm letting designers create durable components, small series and limited editions with confidence and an eye ahead.
From Automotive to Aerospace, a variety of sectors will benefit from Windform® RS: tough, heavy-duty applications withstanding the most harsh environments; accurate, reliable, durable functional prototypes; end use and mission-critical components for the most demanding industries.
Windform® RS addresses applications where durability, ductility and resistance are a must.
