Windform TPU
Class of Material
Thermoplastic Polyurethane
Technology
Selective Laser Sintering
FEATURES
Great shock absorption and traction resistantRubber-like materialSuperior elasticity, flexibility, softness
KEY VALUES
Elongation @ Break 183,1 %Density 0,92 g/cm³Shore A Hardness 73
APPLICATIONS
Car interior components, bellows gimbal, air filter coversObjects of design and fashionPipes, grippers, joints and snap fitsRobotics componentsRubber-like functional prototypes and partsSport footwear and equipment
Technical Properties
Density: 0,92 – 0,98* g/cc
Colour:
BLACK
Particle size (laser diffraction): 55-75 microns (d50)
| Thermal Properties | Test Method | SI Unit | US Unit |
|---|---|---|---|
| Melting point | ISO 11357 | 139,7 - 148,3* °C | 283.46 - 298.94* °F |
* Value after infiltration
Note: The material properties provided herein are for reference purposes only. Data was generated from the testing of parts produced with Windform TPU material under optimal processing conditions. Actual values may vary significantly as they are affected by part geometry and process parameters. Material specifications are subject to change without notice.
Standard Technical Details for Accuracy versus Tolerance:
For parts up to 1 mm (0.039″), the standard tolerance is ± 0,070 mm (0.003″)
For parts up to 3 mm (0.118″), the standard tolerance is ± 0,125 mm (0.005″)
For parts up to 6 mm (0.236″), the standard tolerance is ± 0,150 mm (0.006″)
For parts over 6 mm (0.236″), refer to UNI EN ISO 286-2 JS14 class (linear tolerances).
Technical specifications
Windform TPU is a durable polyurethane material with exceptional rubber-like distinguishing features.
Its mechanical properties make it particularly suited for applications requiring softness, flexibility, elasticity and where robustness is a key requisite.
Windform TPU shows excellent durability and stability; it also combines superior tensile strength with high shock absorption and high abrasion resistance.
Applications
Windform TPU offers numerous advantages for your projects demanding an elastomeric material.
Resistance, flexibility, elasticity and softness are the material characteristics offering a lot of opportunities, from functional prototyping to production.
Thanks to its versatility, it can be used for various applications in many different sectors such as: Automotive (car interior components, bellows gimbal, air filter covers, flexible and resistant parts); Industrial/Robotic (bellows, pipes, grippers; joints and snap fits to connect two parts); Consumer.
Windform TPU is also ideal for Fashion/Design sector, sport footwear and sport equipment (protection and soles).
